China Aluminized Steel Coil
Aluminized steel’s heat shield makes it an ideal, cost-effective choice for fabrications exposed to punishing temperatures: automotive exhaust, plus HVAC and equipment, such as water heaters, furnaces heat exchangers, space heaters, ranges and appliances of multiple sizes. It also performs nicely against exposure to salts.
- Description
Description
Introduction to Aluminized Steel Sheet
Aluminized steel sheet is known for its exceptional flatness and drawability. It is highly recommended for applications that require excellent heat protection and corrosion resistance. Our aluminized steel sheet is available in Type 1 and Type 2, both produced to ASTM A463 specifications.
Applications of Aluminized Steel Sheet
Aluminized steel’s superior heat resistance makes it ideal for HVAC systems and other heat-intensive applications, such as:
- Heat Exchangers
- Commercial Rooftop HVAC Units
- Automotive Mufflers & Exhaust Systems
- Heat Shields
- Ovens
- Water Heaters
- Baking Pans
- Pipe Wraps
- Culverts
- Tubing
… and many more.
Our steel slitting capabilities:
- Two 25 in. slitters in-house with larger slitters at outside processors
- Material Thickness: 0.01/0.250
- Min/Max Slit width: 0.2 in. – 25 in. in-house, larger widths at outside processors
- Min/Max ID: 20 in.
- Slit Width Tolerance: 0.005 in
All coils are available in the following grades, depending on the current inventory:
- CS (CQ): Commercial Steel: Types A, B, and C
- DS (DQ) or FS: Drawing Steel or Forming Steel (Coated Products): Types A and B
- DDS (DDQ): Deep Drawing Steel
- EDDS (IF): Extra Deep Drawing Steel
- HSLAS: High Strength Low Alloy Steels: HSLAS Grade 50-80 and HSLAS-F 50-80
- C1006, C1008, C1010
- Half Hard
- Quarter Hard
Aluminized Specifications
| Material Thickness | 0.014″ through 0.130″ | |||||
| Material Width | 24″ through 61″ | |||||
| ASTM Specification | ASTM A463 | |||||
| Steel Grades |
| |||||
| Coating Weight |
(Type 2 and UL Coating Weights available and other coating weights may be available. Please inquire) | |||||
| Coil Weight | 10,000 lbs. minimum through 55,000 lbs. maximum | |||||
| Coil ID | 20″ and 24″ | |||||
| After Treatment (upon request) |
|
